California Bearing Ratio (CBR) Tests: The Procedure & CBR Values
The California Bearing Ratio (CBR) test is used to measure the strength and stiffness of soil as part of road construction projects. First developed by the California Division of Highways in the 1930s, this type of test remains relevant and is still used around the world today. For example, in Britain, BS 1377-9 specifies CBR tests for assessing the strength of subgrade and subbase materials in civil engineering.
This guide explores everything you need to know, from the CBR test procedure through to the calculations involved and an explanation of CBR values. There’s plenty of ground to cover. Use the links below to navigate to individual sections:
In this blog, we’ll cover:
- What is CBR testing?
- Aren't we beyond CBR testing now?
- CBR testing procedure
- CBR values of soil explained
- How are CBR values calculated?
- Why is a CBR test important in construction?
- How is CBR normally tested on site?
- Does CD225 use CBR values for design?
- Alternative CBR testing methods
- Minimum CBR value for road subgrade
- How we can help.
Tensar has extensive experience in supporting road construction projects. Request a free design assessment to discover how our solutions can enhance performance and value.
What is CBR testing?
The California Bearing Ratio test (CBR test) is a penetration test designed to evaluate the strength of subgrade soil in the design of roads, foundations and flexible pavements, other paved areas and their used materials. Developed by the California State Highway Department, the CBR test has since been widely adopted internationally.
Ultimately, the purpose of CBR testing is to measure soil strength and stiffness crucial for road foundation design. This helps ensure the durability and longevity of pavements under traffic loads.
Aren't we beyond CBR testing now?
Why do I still need a CBR value when my road foundation design is based on modulus?
Forget soil for a moment. Instead, imagine that you’re baking a cake, and think about how sweet the cake will be. And this will depend on the amount of sugar you put in. Instead of measuring sweetness directly, you follow a recipe that lists sugar in cups. Since you don't have a standard cup, you convert cups to grams using a chart and weighing scales. This way, you end up with the right amount of sugar for the desired sweetness.
Similarly, when working with the CBR test, we estimate soil strength using CBR values, even though it's challenging to measure directly. Just as you trust the recipe and conversion chart for the cake, we rely on CBR values to understand soil strength for road design. Keep reading to learn more about how this works!
CBR test procedure
Step 1: Prepare the test material
Place the soil sample in a cylindrical mould and compact it to the specified density and moisture content.
Step 2: Conduct penetration testing
- Insert a 50mm cylindrical plunger into the test material.
- Apply pressure at a constant rate of 1.25mm per minute.
Step 3: Record the load
Measure the load required to achieve penetrations of 2.5mm and 5mm into the material.
Step 4: Calculate the CBR value
Express the recorded loads as a percentage of a standard load obtained from testing a high-quality granular material. This percentage is the CBR value.
CBR test results for soil are expressed as a percentage, e.g., CBR 2.5%. The CBR test compares the penetration resistance of the tested soil to that of a standard high-quality granular material. Typically, a high CBR percentage indicates a harder surface. The result is a ratio which is then multiplied by 100 to generate a percentage value representing the CBR value of soil.
- Formula: CBR = (measured pressure / standard pressure) × 100 %
Step 5: Determine the appropriate CBR value:
Typically, the CBR value at 2.5mm penetration is higher than that at 5mm, so the 2.5mm value is used. If the 5mm value is higher, repeat the test and use the 5mm value if it remains higher.
Step 6: Evaluate subgrade stabilisation needs:
Based on the CBR value, assess whether the subgrade needs stabilisation. If the CBR value is low, consider stabilisation methods, such as mechanical soil stabilisation or adding materials to working platforms to improve soil strength.
Step 7: Conduct tests:
Perform the California Bearing Ratio test either in-situ, accounting for seasonal moisture variations, or in a lab using undisturbed or remoulded samples. Laboratory tests should simulate the subgrade moisture content and expected site disturbancesfree design assessment
Discover how we can help you make time and cost savings on your next road construction project.
Get in touch
CBR values of soil explained
The CBR value of soil is the ratio of force required to penetrate a soil mass with a standard circular piston to a specific depth at the rate of 1.25 mm/min, to that required for the corresponding penetration of a standard material, expressed as a percentage.
The CBR value increases with the surface hardness. For example, the CBR value of clay soils generally has a CBR of 2%, while sands may reach 10%. High-quality sub-base materials typically range between 80% and 100%, making them ideal for providing strong support for the structures above.
CBR values provide a quantified estimate of soil strength and surface stiffness suitable for use in road foundation design. Understanding CBR values helps in determining the CBR value of soil and its appropriateness for construction purposes.
To enhance the performance of road foundations, geosynthetics such as Tensar Basetex can be integrated into the design to improve soil stability and load bearing capacity.
Why is the CBR test important in construction?
The CBR test is important in a lot of construction applications.
- Road and pavement construction: The CBR value is a key input in many empirical and mechanistic-empirical pavement design methods. A higher CBR value indicates a stronger material, allowing for a thinner pavement section, which translates to significant cost savings in material and construction time.
- Foundation stability: The CBR value can also provide a general indication of the bearing capacity of soils for light structures, such as building foundations, although more sophisticated geotechnical investigations are typically required for critical structures.
- Compliance with standards: This helps ensure that construction projects meet industry standards and regulations, such as those outlined in BS1377.
- Value engineering: Understanding the CBR of the subgrade and granular layers allows engineers to predict how the pavement will behave under traffic loading and environmental conditions. By accurately determining the strength of the underlying layers, engineers can optimise pavement designs to lower costs whilst maintaining performance.
Using CBR values for road design
Road and highway construction rely heavily on accurate road foundation design methods, such as those outlined in CD225 ‘Design for New Pavement Foundations’. These methods require subgrade soil conditions to be classified by subgrade surface modulus. Since measuring this modulus directly is challenging, it is estimated based on CBR values. CD225 provides a CBR formula to convert the California Bearing Ratio to subgrade surface modulus.
So far, so good, but CBR testing is a little difficult, and the results vary greatly with moisture content. The design value should reflect the ‘equilibrium’ moisture content and the condition expected during the service life of the road foundation. It is going to require some calibration and estimation. Although the CBR formula to convert CBR to modulus seems precise, the input value of CBR may not be.
CBR testing is rarely carried out during a regular site investigation. Instead, a CBR value is usually obtained indirectly from another in-situ test, such as the plate load test (PLT), or the dynamic cone penetrometer (DCP) test. Calibration charts enable the conversion of penetration results to CBR value. Then, from CBR, we use the equation to estimate the subgrade surface modulus.
Plate load test in action to derive CBR values
Why do we still use CBR values for road design?
Despite most national road construction methods relying on subgrade surface modulus for foundation design, this parameter is rarely measured directly on-site. Engineers typically use CBR values to estimate the modulus.
The physical properties of a soil control its strength and stiffness. The relationships between these properties are complex and not fully understood. The CBR test, first introduced in the 1930s, has stood the test of time and is generally accepted to be a practical and cost-effective measure that gives an indication of both strength and stiffness.
Highway engineers and geotechnical engineers have become familiar with CBR values as a measure of subgrade strength, to the point where many engineers can give a good initial estimate of CBR values on-site by pressing a thumb or heel into the subgrade surface. This approach, while lacking precision, is widely accepted in geotechnical engineering and gives experienced engineers the confidence to estimate CBR values based on their on-site assessments.
In contrast, quoting a shear strength value in kPa implies a level of precision that may not reflect the reality. Charts are available to estimate CBR test results based upon a description of soil type, construction condition and moisture content. CD225 allows the use of Table C1 from LR1132 to estimate the CBR value for foundation design where no CBR measure is available.
Table C1 reproduced from LR1132
Because of its longevity, the results from many other soil tests have been calibrated to equivalent CBR values, and good engineers have a concept of this. California Bearing Ratio, therefore, provides a common scale, understood by all and adopted as a common input value for various design methods in road construction. This standardisation ensures road surfaces are built with the right strength and durability.
How is CBR normally tested on-site?
CBR tests involving the penetration of a standard cylindrical plunger are rarely done during standard site investigations. Instead, alternative test methods are used, and the CBR value is obtained using correlation charts. As mentioned above, the alternative test methods most commonly used are DCP or PLTs. Correlations between these test values and CBR test results are well established and widely accepted.
Does CD225 use CBR values for design?
The UK Design Manual for Roads and Bridges CD225 – ‘Design for new pavement foundations’ proposes a restricted design method based upon the design subgrade surface modulus. This modulus is taken as the lower value during construction or when equilibrium is reached in service.
However, CD225 recognises that direct measurement of subgrade surface modulus is impractical, and that design subgrade surface modulus will need to be estimated. CD225 suggests that the process outlined in TRL document LR1132, ‘The structural design of bituminous roads’, may be used when estimating the short and long-term subgrade surface modulus. LR1132 suggests CBR values provide the best practical means of estimating subgrade surface modulus.
CD225 then requires that the equation below be used to convert the CBR value to the subgrade surface modulus.
E = 17.6(CBR) 0.64
The equation is limited to CBR values between 2% and 12% and soils of maximum particle size of 20mm.
Although the use of CBR values is proposed, the use of a CBR test is not a requirement. Alternative in-situ test methods are accepted that can be correlated to CBR values. Cone penetrometer testing is specifically mentioned in LR1132.
What CBR value is acceptable for road subgrade?
CD225 notes that subgrades with a design subgrade surface modulus lower than 30 MPa are unsuitable to support the construction of a pavement. That equates to a CBR value of approximately 2%. Below that, subgrade replacement or subgrade improvement is necessary. CD225 includes mechanical stabilisation using geogrids as one suitable option. If you're dealing with weak subgrades in your project, consider filling out the subgrade stabilisation form for expert support from Tensar.
Alternative CBR testing methods
Limitations of the CBR test
While widely used, the CBR test has several limitations that engineers must consider for accurate interpretation and application of results:
- Different soil types affect CBR: The CBR value is inherently dependent on the characteristics of the soil being tested. Clay, sand, gravel and organic soil are all different in saturation, moisture and compressibility.
- Moisture of soil: CBR values are highly sensitive to the moisture content and dry density of the soil. Small variations in these parameters can lead to significant changes in the measured CBR. This is particularly critical in the field where moisture conditions can fluctuate.
- Scale effect: The CBR test uses a relatively small plunger (50 mm diameter) and tests a small volume of soil. This means the results may not always be representative of the bulk behaviour of a large soil mass, especially in heterogeneous soils.
- In‑situ vs Lab Variation: Laboratory CBR tests require the preparation of compacted samples. The process of compaction, even under controlled conditions, can alter the soil structure and properties from their in-situ state, potentially affecting the test results.
Alternative to CBR testing
Dynamic Cone Penetrometer and Plate Load Tests are common in-situ alternatives.
There are also alternative in-situ tests for measuring modulus values, like the falling weight deflectometer (FWD) and light weight deflectometer (LWD) tests. The LWD equipment is handheld and can be correlated to the FWD equipment to improve accuracy. These dynamic tests are less common but provide a more direct measure of the modulus value of the subgrade, which aligns with the road foundations DMRB-CD225 standards.
Plate Bearing Test vs CBR
The Plate Bearing Test (PBT) and the CBR test are both used to assess the bearing capacity of soils, but they differ significantly in their methodology, scale, and the type of information they provide.
For more information about the Plate Bearing Test, read more: Plate Load Test: Uses, Method, Plate Size and Interpretation
Plate Bearing Test (PBT) | California Bearing Ratio (CBR) Test | |
Principle | Measures the load-deformation characteristics of a soil mass under a rigid plate. | Measures the resistance of a soil to penetration by a standard plunger. |
Load Area | Larger, rigid plate (e.g., 300mm, 450mm, 600mm diameter). | Smaller, standard plunger (50mm diameter). |
Depth of Influence | Deeper reflects the properties of a larger volume of soil. | Shallower primarily reflects the properties of the material immediately beneath the plunger. |
Output | Bearing capacity (pressure for a given settlement), modulus of subgrade reaction (k-value). | Dimensionless ratio (CBR value). |
